- Pipe modules start from released routes and end interfaces
- Geometry, bends, and labels should be visible in the package
Cooling Pipe Modules
Cooling Pipe Modules
Prefabricated welded pipe runs for secondary-side loops, rack distribution, and connection assemblies.
Drawing-based build
Protected delivery
Where it fits
Prefabricated pipework between defined project interfaces.
Cooling pipe modules translate customer routing, end connections, pressure requirements, and packing zones into stainless pipe sections ready for the next integration step.
[02]
Prepared interfaces
- Flange, weld, thread, hose, or clamp standards are project inputs
- Pressure, medium, and test protocol stay customer-defined
[03]
Protected delivery
- Cleaning, capping, labeling, and packing are planned by module group
- Site routing and commissioning remain outside the module scope
Product family overview
Cooling pipe modules prepared for project handoff.
01 / Released drawing
Released route
OD, wall thickness, spool length, route geometry, and end connections follow the released drawing.
02 / Project-defined
Stainless material
Austenitic stainless tube grade follows the project package.
03 / When specified
Weld process
Weld bead, branch forming, grinding, and fixture control follow the approved drawing and weld requirement.
04 / Clean delivery
Passivation & rinse
Pickling / passivation, DI-water rinse, drying, and protected ends can be included in the handoff package.
05 / Interface control
Clean assembly
Ports stay capped, labels remain visible, and interface protection is planned by module group.
06 / Handoff ready
Packing
Individual labels, protected wrapping, grouped packing, and export crates can be aligned to the delivery plan.
Scope boundary
Customer defines the system. Chelsey fabricates the hardware.
This section keeps the manufacturing scope, interface inputs, and handoff boundary visible without turning the family page into a system-design page.
Drawing package
Starts from customer drawings, BOMs, samples, or interface requirements.
Interface discipline
Connection standard, material, seals, and component preferences should be confirmed before fabrication.
Fabrication support
Stainless fabrication, component integration, cleaning, capping, and labeling stay inside the approved scope.
Quality boundary
Test support per customer protocol, packing, and export-ready delivery can be aligned.
Buyer handoff FAQ
Frequently asked questions
01What should be prepared before a product-family review?
Send drawings, BOMs, samples, interface requirements, pressure requirements, component preferences, quantity, and packing destination.
02Does Chelsey define the full cooling system?
No. Chelsey fabricates and integrates hardware within the customer or integrator design package.
03Can customer-specified components be used?
Yes, when the selected valves, quick disconnects, hoses, fittings, or sensors are available and compatible with the approved scope.
04Can testing be included?
Test support per customer protocol, leak review, cleaning, visual inspection, and packing checks can be aligned before delivery.
Send the drawings.We review the build.
Share pipe size, material, pressure, interface type, quantity, fluid medium, customer test protocol, and packing destination for a focused fabrication review.
Drawing / layoutPipe sizeMaterial gradeDesign pressureInterface typeValve requirementTest pressureQuantity
